Compact 5mW 532nm Laser Wavelength Diode Pumped Solid State (DPSS) Laser Manufacturer

Laser Wavelength:

532nm
Laser Color:

Green Dot Laser Beam
Output Power:

5mW
Beam Size:

≤10mm@20m
Housing Material:

14*60mm Black Anodized Aluminum

 Inquire Add to Basket

Model: AM532D05G1
Brand: AIMLASER
Code: 90132000.99
Color: Green, DPSS, Visible
Wavelength: 520nm
Type: CW, Dot

Product Description

Product Description of Compact 5mW 532nm Laser Wavelength Diode Pumped Solid State (DPSS) Laser Manufacturer

AimLaser provides customized Diode Pumpled Solid State DPSS Laser Modules with different output power, beam size and dimensions, which uses optical glass lens and input voltage various from 3V to 12V DC.

The green laser modules possess characteristics of compact size, low power consumption, high stability and low cost, now are widely used in industrial laser surveying instrument, medical laser instrument, precision instruments for laser positioning, laser detecting, laser aiming, laser alignment and laser scanning applications; and also consumer products like nightwear sporting products, gun sight lasers and automotive interior ambient light etc.

※ 532nm 5mW DPSS Laser Module Descriptions

The AM532D05G1 is a green laser module subassembly with collimated beam. The maximum laser output power is 5.0mW at 532nm.

※ 532nm 5mW DPSS* Laser Module Optical and Electrical Characteristics*

ITEM	SPECIFICATIONS
Model Number	AM532D05G1 Green DPSS Laser Module
Wavelength	532nm
Output Power	≤5.0mW
Laser Mode	CW
Beam Size	≤10mm@20m
Divergence	0.2mrad
Optics	Optical Glass Lens
Operating Current	<250mA
Operating Voltage	3VDC
CDRH Class	Class IIIa
Circuit control	Auto Power Control (APC)
Circuit Protection	Static, Surge, and Reverse Polarity Protected
Working Temperature	0℃ to 45℃
Storage Temperature	-20℃ to 70℃
Dimensions	Φ14x60mm (Driver Inside)
Housing Material	Black Anodized Aluminum
Life Span	5,000Hrs
