Industrial Green Beam Laser Pointer 520nm 30mW 3V Adjustable Laser Modules

Laser Wavelength:

520nm
Laser Color:

Dot Green Laser Beam
Output Power:

30mW
Beam Size:

≤2.0mm@1m
Housing Material:

Full Brass or Black Anodized Aluminum

 Inquire Add to Basket

Model: AM520D30G1
Brand: AIMLASER
Code: 90132000.99
Color: Green, Visible
Wavelength: 520nm
Type: Dot

Product Description

Product Description of Industrial Green Beam Laser Pointer 520nm 30mW 3V Adjustable Laser Modules

AimLaser provides customizedGreen Dot Laser Diode Modules with different output power, beam size and dimensions, which uses optical glass lens and input voltage various from 3V to 12V DC.

The green laser modules possess characteristics of compact size, low power consumption, high stability and low cost, now are widely used in industrial laser surveying instrument, medical laser instrument, precision instruments for laser positioning, laser detecting, laser aiming, laser alignment and laser scanning applications; and also consumer products like nightwear sporting products, gun sight lasers and automotive interior ambient light etc.

※ 520nm 30mW Dot Green* Laser Diode Module Descriptions*

The AM520D30G1 is a green laser module subassembly with collimated beam. The maximum laser output power is 30.0mW at 520nm.

※ 520nm 30mW Dot Green* Laser Diode Module Optical and Electrical Characteristics*

ITEM	SPECIFICATIONS
Model Number	AM520D30G1 Dot Green Laser Diode Module
Wavelength	520nm
Output Power	≤30.0mW
Laser Mode	CW
Beam Size	≤2.0mm@1m
Divergence	0.2mrad
Optics	Optical Glass Lens
Operating Current	<240mA
Operating Voltage	3V DC
CDRH Class	Class IIIb
Circuit control	Auto Constant Current (ACC)
Circuit Protection	Static, Surge, and Reverse Polarity Protected
Working Temperature	-10℃ to 50℃
Storage Temperature	-40℃ to 80℃
Dimensions	Φ12x40mm (Driver Inside)
Housing Material	Full Brass or Black Anodized Aluminum
Life Span	8,000Hrs
