TTL Modulation 450nm 30mW Blue Laser Pointer Module

Laser Wavelength:

450nm
Laser Color:

Blue Dot Laser Beam
Output Power:

30mW
Beam Size:

≤2.0mm@1m
Dimensions:

12x40mm Brass or Black Anodized Aluminum

 Inquire Add to Basket

Model: AM450D30G1M
Brand: AIMLASER
Code: 90132000.99
Color: Blue, Visible
Wavelength: 450nm
Type: Pulse, CW, Dot, TTL

Product Description

Product Description of TTL Modulation 450nm 30mW Blue Laser Pointer Module

AimLaser provides customized Blue Dot Laser Diode Modules with different output power, beam size and dimensions, which uses optical glass lens and input voltage various from 3V to 12V DC.

The blue laser modules possess characteristics of compact size, low power consumption, high stability and low cost, now are widely used in industrial laser surveying instrument, medical laser instrument, precision instruments for laser positioning, laser detecting, laser aiming, laser alignment and laser scanning applications; and also consumer products like nightwear sporting products, gun sight lasers and automotive interior ambient light etc.

※ 450nm 30mW Blue Dot Laser Diode Module Descriptions

The AM450D30G1M is a TTL modulated blue laser module subassembly with collimated beam. The maximum laser output power is 30.0mW at 450nm.

※ 450nm 30mW Blue* Dot Laser Diode Module Optical and Electrical Characteristics*

ITEM	SPECIFICATIONS
Model Number	AM450D30G1M Blue Dot Laser Diode Module
Wavelength	450nm
Output Power	≤30.0mW
Laser Mode	Pulse (TTL Modulation)
Beam Size	≤2.0mm@1m
Divergence	0.6mrad
Optics	Optical Glass Lens
Operating Current	<160mA
Operating Voltage	5V DC
CDRH Class	Class IIIb
Circuit control	Auto Power Control (APC)
Circuit Protection	Static, Surge, and Reverse Polarity Protected
Working Temperature	-10℃ to 50℃
Storage Temperature	-40℃ to 80℃
Dimensions	Φ12x40mm (APC Inside)
Housing Material	Brass or Black Anodized Aluminum
Life Span	8,000Hrs
