Green laser generation method

(1) Up-conversion pumped green laser is doped with rare earth ions in solid materials, pumped with semiconductor lasers or other light sources, and directly utilizes the energy level transition of rare earth ions to produce green lasers. This method is based on the up-conversion effect, that is, the wavelength of the lasing light is smaller than the wavelength of the pump light. The upconversion luminescence mechanism of rare earth ions can generally be divided into three processes: excited state absorption, energy transfer and photon avalanche.

(2) The semiconductor laser directly emits green light. The semiconductor laser is a miniaturized laser with a PN junction or PIN junction composed of a direct band gap semiconductor material as the working material. There are three main excitation methods for semiconductor lasers, namely, electrical injection, optical pumping and high-energy electron beam excitation.

According to wavelength and application fields, semiconductor lasers can be roughly divided into long wavelength and short wavelength. On the short-wavelength side, due to difficulties in material preparation and device technology, the research progress of semiconductor green lasers has been relatively slow, and has not reached the practical level for a long time.

(3) Nonlinear optical crystal frequency doubling method. This is the more commonly used method to realize green laser. This method can be divided into direct method and indirect method. The direct method is to directly input the semiconductor laser to the wavelength conversion element, and obtain the green laser output after frequency multiplication. This method is characterized by simple structure, easy frequency doubling, and high conversion frequency, but the output green laser has a wider line width and poor wavelength stability. The indirect method can be divided into two kinds: a. The solid-state laser activated by rare earth ions such as Nd3+ and Er3+ is pumped by a semiconductor laser, and then the frequency doubling is achieved through the wavelength conversion element. This method is more complicated in structure, but it can get good laser spectrum and beam characteristics. In addition, this method can also take advantage of the long energy level life of solid-state lasers to achieve energy accumulation and obtain high-energy laser output. b. The use of self-frequency-doubling crystal materials that can not only emit laser but also realize wavelength conversion at the same time realize laser output, such as potassium nitrate co-doped with magnesium oxide and Qinyi aluminum borate and KTP:Cr
